Rugged 5-Port Switch




IDAN® LAN10257 Overview

RTD's IDAN LAN10257 is a standalone 5-port Gigabit Ethernet Switch in a passively cooled milled aluminum enclosure delivering performance from -40 to +85°C.

Key Features

  • BroadCom BCM53115 Gigabit Ethernet Switch
  • 5 full duplex unmanaged Gigabit Ethernet ports (auto-configured: any of the ports can be the uplink and the rest will be downlinks)
  • Ports have automatic MDI crossover to eliminate the need for crossover cables
  • Supports Jumbo frames up to 9720 bytes
  • COTS pre-configured with no additional engineering fees
  • -40 to +85°C operating temperature
  • ITAR-Free, U.S. Commerce EAR99 Classification

Specifications

Connector Interface

  • 9-pin D-Sub Ethernet connectors
  • Push-pull power connector
  • P1, P2, P3, P4, P5: Ethernet ports 1-5

Environmental

  • Operating temperature: -40 to +85°C,
    90% humidity non-condensing
  • Storage temperature: -40 to +85°C
  • Passively convection cooled without forced air, fans, or moving parts

Power

  • Power input requirements: 8-36 Vdc
  • Power consumption: 1.2 - 2.1 W (consult the hardware manual for detailed power consumption information)

Physical Characteristics

  • 0.950 x 6.617 x 5.930 inches (24.13 x 168.15 x 150.62 mm)
  • 1.5 lbs. (0.6 Kg.)
  • Aluminum Alloy - 6061, Temper-T6
  • Exterior finish: light gray polyurethane
    (FED-STD-595 color 36495)

+ What's Included

  • System Components
    • LAN10257 Ethernet Switch
    • AC power adapter cable
    • 5 D-sub to RJ-45 adapters
    • Lid, Base, and Bolts
  • Companion CD with user manual
  • Standard 1-year Warranty
